TOTlME diamond material is a synthetic diamond sintered under high temperatures and pressures.
PCD(Polycrystalline diamond) is ideal for non-ferrous metals and non-metals.
●Applicable for non-ferrous metals, non-metals turning, milling and other various type of cutting.
●Long tool life due to extreme hardness.
●Capable of high cutting speeds which increases cutting productivity.
●Reduced edge build-up allows for high precision cutting.
●Diversified applications for cutting of non-ferrous materials andnon-metals.
|
Grade |
Grain Size (μm) |
Transverse Rupture Strength(Gpa) |
Work Material |
Features |
|
TDC2000 |
6 |
1.7 |
CFPR Composite Materials |
Special blade design, excellent wear resistance |
|
TDA1000 |
10 |
1.4 |
Medium and Low Si Aluminum Alloy Si<13% |
Demonstrates optimum wear and fracture resistance and excellent edge sharpness. |
|
TDA1500 |
25 |
1.2 |
High Si Aluminum Alloy Si>13% |
Exhibiting wear and fracture resistance in cutting of aluminum alloy |
|
Work Material |
Grade |
Cutting Condition |
||
|
Vc(m/min) |
f(mm/rev) |
ap(mm) |
||
|
Medium and Low Si Aluminum Alloy Si<13% |
TDA1000 |
900-3000 |
0.1-0.4 |
0.1-0.4 |
|
High Si Aluminum Alloy Si>13% |
TDA1500 |
300-700 |
0.1-0.4 |
0.1-0.4 |
|
Carbon Fiber |
TDC2000 |
200-1500 |
0.05-0.3 |
0.1-3.0 |
